Atdec AD-VWP Heavy-Duty Video Wall Pop-Out Mounting Bracket
Atdec AD-VWP Heavy-Duty Video Wall Pop-Out Mounting Bracket
Couldn't load pickup availability
SKU:
Atdec ADB-VWP: Modular Video Wall Pop-Out Mounting Bracket
The Atdec ADB-VWP is a heavy-duty pop-out mounting bracket designed as a core component of Atdec’s modular digital signage system. Engineered for professional video wall installations, the ADB-VWP allows for seamless integration onto modular rails, providing a scalable solution for multi-display arrays. Its primary purpose is to combine a high-capacity load rating with front-serviceable pop-out functionality, ensuring that maintenance in complex configurations remains efficient and straightforward.
Modular Integration and Serviceability
The ADB-VWP utilises a precision-engineered pop-out mechanism that extends the display forward, granting technicians immediate access to the rear of the screen and integrated media players without disrupting the rest of the video wall. This modular bracket is designed to slide directly onto Atdec’s horizontal mounting rails, allowing for lateral movement and precise positioning during the installation process. The pop-out functionality features a "push-to-release" design, which can be fine-tuned via six different force settings to accommodate varying display weights and depths.
For ease of service, the bracket includes integrated kickstands that prop the display open during maintenance. This ensures the installer has a stable, hands-free environment for cabling or hardware swaps. The ADB-VWP is an ideal choice for recessed installations or large-scale multi-row video walls where rear access is otherwise restricted.
Precise Alignment and Heavy-Duty Performance
Achieving a uniform, gap-free appearance is critical for professional digital signage. The ADB-VWP provides extensive post-installation fine-tuning, including vertical, lateral, and depth adjustments. These toolless controls allow for the micro-alignment of each display in the array, ensuring a perfectly flat and continuous visual surface.
Constructed from robust steel with a professional black finish, the bracket is rated to support displays up to 70kg. It features a wide range of VESA compatibility and is equipped with security features, including a lockable safety point that prevents unauthorised pop-out or removal of the display in public environments.
Comprehensive Technical Specification Data
| Feature | Detail |
| Product Code | ADB-VWP |
| System Compatibility | Atdec Modular Digital Signage Rails |
| Display Capacity | 70 kg |
| Pop-Out Extension (Max) | 315 mm |
| Minimum Depth from Wall | 110 mm |
| Vertical Fine-Tuning | 13 mm |
| Lateral Adjustment | Rail-dependent (with bracket fine-tune) |
| Depth Fine-Tuning | +/- 7 mm |
| VESA Compatibility | Up to 400x400 (Expandable with adapters) |
| Security | Lockable Security Point |
| Material | Steel |
| Warranty | 10 years |
See manufacturer website for specific product warranty information.
